THE LINE LOSS PRO FILTER
The Line Loss Pro Smart Energy Filter is comprised of four different inductor designs. Two of the designs vary with the load, in amperes, while the others are a fixed inductance.
Throughout the day, the profile of the load of the particular panel that is comprised of circuit breakers varies as well. Within a facility, you will find loads that maintain a constant load 24 hours per day, but more often than not, all loads turn off and on. Thus the variability of the inductor is useful.
​
Electrical Loads that have a capacitive leading power factor, as opposed to a lagging inductive power factor profile to them. The inductance in the Line Loss Pro negates or “offsets” by the use of vector analysis (trig) “reduces” the capacitance of the load and thereby saves energy.
​
Specific recommendations on which facility types and component usage of power for equipment and lighting would typically provide better results with installation of the LLP device: LED lighting circuits, variable speed drive circuits for the air handler units on each floor, as well as switch mode power supplies that you would find on dedicated circuits for servers. Sometimes those dedicated server circuits have a UPS system wired between them and the panelboard. This is a great application as well. All of these loads have a capacitive leading power factor profile to them. The inductance in the Line Loss Pro negates, “offsets” are reduces the capacitance of the load and thereby saves energy.
5
200+
20
24x
VALIDATION OF SAVINGS
We utilize historical consumption data and industry standard Key Point Indicators (KPI's) to compile and provide a comprehensive analysis to validate and report actual kWh (kilowatt hour) usage reduction and savings. (Customer Participation is required)
